Panel Level Packaging Consortium

Focus Project: Process Optimization and Cost Modelling

Key benefits

Actual exploitation remains one of the top-line concerns and limits of FOPLP technology. The project intends to expand the current cost model with a granular routing model, also covering  other packaging architectures and opportunities for introducing the required software adjustments with an eye on ease of use.

Main goals

  • Reviewing the entire process flow with consideration for variations and interactions in the processes and materials
  • Producing handling and automation concepts
  • Designing and preparing test vehicles
  • Capturing market and technology trends and establishing a networking platform
  • Expanding the current cost model

Warpage and die shift

Focus Project Thrust 1


Key benefits

Exploiting die placement and embedding technology for fine line wiring FOPLP.

Main goals

  • Process developments for high precision die placement
    and defined and controlled die shifting
  • Evaluation of materials for temporary die attach andembedding
  • Investigations of additional parameters on die shift and warpage, such as package density, Si density, ambient conditions, component surface, aspect ratio and others
  • Strategies for controlled warpage


Extreme wiring

Focus Project Thrust 2


Key benefits

Exploiting the technology limits of the fine line wiring.

Main goals

  • Realization of 5 μm L/S in up to 3 layers
  • Use of adaptive imaging for optimized yield
  • Development towards 2 μm L/S on full IZM panel size (600 x 600 mm²)
  • Exploitation of »via-less« Chip-to-RDL interconnection (Suitable structures on chip pad (e. g. small Cu pillar) are used for the penetration through the dielectric film (first RDL layer) during lamination forming an interconnection.)


Migration effects

Focus Project Thrust 3


Key benefits

Exploiting the migration limits of the fine line wiring.

Main goals

The physical background of these migration phenomena is not new, but larger dimensions are less prone to defects. Therefore miniaturization of the wiring to 2 μm lines/space may face physical/chemical limitations.

Material migration is driven by concentration gradient, temperature gradient, electrical field and mechanical stress Cu is far more resilient to electro-migration compared to Al, but Cu has a much higher tendency to migrate through the dielectric layer further increased by humidity.



Membership

The consortium includes a dedicated corporate membership category for commercial partners. Individual payment plans are available on request, with cancellation options from year 2. The membership fee covers the fundamental research in all R&D activities.

Research Results

  • Participation in the research project’s steering and controlling
  • One-on-one technology transfer

Reports

  • Quarterly workstream reports
  • Half-yearly management and technical reports

Meetings

  • Quarterly virtual meetings online
  • Half-yearly on-site meetings in Berlin, including in-depth workshops on specific topics

A Look Back at the Previous Consortium
(2016 - 2019)

Fraunhofer IZM’s expertise in wafer level packaging and substrate technology represented the nucleus from which the Panel Level Packaging Consortium grew to include 17 industrial partners in its original incarnation in 2016. The international consortium achieved its headline goals and made significant technical progress in the field of large-area fan-out panel level packaging.

All partners contributed to the progress and success of the PLP consortium. Several test layouts were designed for process development on panel sizes of 18”x 24”. The implementation and improvement of die shift compensation and the monitoring and evaluation of thickness and warping were made possible in a joint effort of the different workstreams, using over 300,000 test chips. A combination of wafer-level (thin film) processing and PCB-like substrate processing was developed for this metal routing process.

An automated electrical test routine was successfully implemented for the demonstrators. Building on the technological progress, a complex cost  model was introduced to allow cost analysis and calculation at a granular level of detail in the reference applications, including process, material and design options, panel utilization, and scalability.
