Panel Level Packaging is on the way to the next level: PLC 2.0
More than 50 international guests gathered at Fraunhofer IZM for the first kickoff meeting in mid of february to mark the great news: After the international Panel Level Consortium 1.0 achieved its ambitious goals for the project in 2019 with significant technical progress in the field of large-area Fan- Out Panel Level Packaging, a new consortium – consequently called PLC 2.0 – has been formed to continue on that trajectory, with special focus on ultra-fineline routing, including an exploration of migration effects as well as warpage and die shift on large-area panels.
The PLC 2.0 project officially got under way on 1 February 2020 and is projected to pursue its goals over two years. The consortium currently consists of 17 international companies spread across the entire globe. Companies of all shapes and sizes can contribute, with consortium members ranging in size from 300 to more than 122,000 people, working as young actors in their field or long-established businesses with histories going back to 1832, or being located in one case at 1000 meters above sea level.
To date, the consortium includes: Ajinomoto Fine-Techno Co., Amkor Technology, ASM Pacific Technology Ltd., AT&S Austria Technologie & Systemtechnik AG, Atotech, BASF, Corning Research & Development Corporation, Dupont, Evatec AG, FUJIFILM Electronic Materials U.S.A., Hitachi Chemical Company, Ltd., Intel Corporation, Meltex Inc., Nagase ChemteX Corporation, RENA Technologies GmbH, Schmoll Maschinen and Semsysco GmbH. Other companies interested in joining the PLC 2.0 still have an opportunity to do so until summer 2020.
The research and development work of the PLC 2.0 consortium will continue the efforts of PLC 1.0, but focus on a set of specific targets. Breaking with the structure chosen for PLC 1.0, there will be only one corporate membership category, reflecting the successful implementation of the workflow. In addition, Fraunhofer IZM has further extended its Panel Level Packaging line to include several new facilities, such as a new high-speed assembly machine, new lithography tools breaking the 1 μm resolution barrier, and new plating and etching tools.
The investment for this equipment was made possible by funding support from the German Federal Ministry of Education and Research (Research Fab Microelectronics Germany). More information will be published regularly over the course of 2020.
